Energy storage mobile charging robot

Energy storage mobile charging robot

The mobile charging robot supports multiple charging standards, CCS1/CCS2/GB/T

  • Item No :

    Mobile Robots
  • Order(MOQ) :

    1
  • Product Origin :

    Hefei, China
  • Color :

    White
  • Lead Time :

    30 days
  • Power :

    184.32kWh

Product Description

TThe mobile energy storage charging robot is like an "energy manager". It can move freely in parking lots, roadside parking spaces and other places where vehicles are located according to the charging instructions issued by the vehicle.

Product Features

  • It comes with a 60KWH to 200KWH large-capacity lithium battery energy storage package
  • It organically integrates charging technology, energy storage technology, and intelligent driving technology
  • It realizes unmanned mobile charging services and mobile energy storage services
  • It can also occupy parking spaces on behalf of others, realizing a new service ecosystem of charging, energy storage, and parking at the park level

Technical Parameters

Host size 2030*1050*1344.5MM
Charging gun 1 (with 3.5m gun line)
Rated input voltage DC 480V-700.8V
Rated input voltage AC 260V-530V
Rated output voltage 750VDC MAX value
Maximum output current MAX 150A
Built-in charging pile specifications 60KW/750VDC(380VAC)
Ambient temperature -30℃~60℃
Rated power 184.32kWh
Rated voltage 614.4V
Charging pile power 60KW
Charging Current 150AMAX
Maximum climbing grade 8%
Vehicle weight 2100kg
Altitude ≤2000m
Protection level IP54
Startup method Scan the QR code



Adaptation to multiple scenarios, highlighting broad value



  1. Residential communities - a new experience of comfortable charging: When returning home at night, car owners no longer need to wander around the community to find charging piles, nor do they need to worry about not being able to charge because the charging piles are occupied. The mobile energy storage charging robot silently "patrols" in the community, using the idle parking time of vehicles at night to automatically identify vehicles with insufficient power and go to charge. This not only provides great convenience for residents and improves the comfort of life, but also provides an innovative and cost-effective solution to the problem of charging pile transformation in old communities, allowing new energy vehicles to easily "endurance" in the community, helping green life to enter thousands of households.
  2.  Commercial center parking lot - consumption and charging are not wrong: In the bustling commercial center, the flow of people and vehicles is highly dense, the parking time of vehicles is short and the charging demand is scattered. The mobile energy storage charging robot takes advantage of its flexibility, moves quickly in the parking lot, and accurately captures every vehicle that needs to be charged. Consumers can quickly recharge their cars during short breaks in shopping, dining or leisure and entertainment, without having to change their itinerary due to charging. This has greatly improved the service quality and attractiveness of commercial venues, achieved seamless connection between commercial activities and vehicle charging, and injected new energy into the city's commercial vitality.
